Ubiquiti UNVR-Pro
UniFi Protect Network Video Recorder Pro — 7-Bay 2U Rack-Mount NVR for professional surveillance deployments.
Key Features
- 7x 2.5"/3.5" HDD/SSD bays for massive storage capacity
- Supports up to 24 4K cameras or 70 Full HD cameras
- Up to 60 days of continuous recording
- Quad ARM Cortex-A57 @ 1.7 GHz processor with 8 GB RAM
- 1x 10G SFP+ port + 1x GbE RJ45 port
- 1.3" touchscreen display
- Power redundancy support (USP-RPS compatible)
- 2U rack-mountable form factor (SGCC steel)
- UniFi Protect and UniFi Access integration
- Door Access support
- NDAA Compliant
Specifications
| System | |
|---|---|
| Processor | Quad ARM Cortex-A57 @ 1.7 GHz |
| Memory | 8 GB |
| Display | 1.3" touchscreen |
| Management | Ethernet (UniFi Protect / UniFi Access) |
| Storage | |
| HDD Bays | 7x 2.5"/3.5" HDD/SSD |
| Max Cameras | 24x 4K or 70x Full HD |
| Recording Duration | Up to 60 days |
| Network | |
| Networking Interface | 1x 10G SFP+ port, 1x GbE RJ45 port |
| Power | |
| Max Power Consumption | 160W |
| Max Power Budget for Drives | 135W |
| Power Supply | AC/DC, internal, 200W |
| Power Method | Universal AC input (100-240V AC, 3A Max, 50/60 Hz) + USP-RPS DC input (11.5V DC, 13.91A) |
| Power Redundancy | Yes (USP-RPS) |
| Physical | |
| Form Factor | Rack mount (2U) |
| Weight | 9.2 kg / 20.3 lb (without brackets), 9.5 kg / 20.8 lb (with brackets) |
| Enclosure Material | SGCC steel |
| Environment | |
| Operating Temperature | -5 to 40°C (23 to 104°F) |
| Operating Humidity | 5 to 95% noncondensing |
| Compliance | |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
