TNR6216P16-V5 4K 16-Channel PoE NVR
TNR6216P16-V5 4K 16-Channel PoE NVR
All prices are subject to change without notice.
Available in stock
Mid-size 4K network video recorder with 16 built-in PoE ports. Records up to 16 IP cameras at up to 8MP (4K) with 160 Mbps incoming bandwidth and two SATA bays for extended retention.
Part of the OvixWatch recorder line: H.265/H.264 dual-codec recording, ONVIF camera support, HDMI and VGA output, and built-in smart analytics (perimeter intrusion, tripwire, object abandoned/missing detection). Remote access from anywhere with the SuperCam Plus app (iOS & Android, QR-code plug-and-play setup) or the NVMS desktop management software for multi-site installations. NTSC, US power plug. 1-year warranty.
16 channels · 16 PoE ports · 160 Mbps · 2 SATA bays
Couldn't load pickup availability
Shipping & Rerturns
Shipping & Rerturns
📦 Shipping Policy
- Processing Time: Orders ship within 1–2 business days.
- Shipping Methods: We use reliable carriers like UPS, FedEx, and USPS.
- Tracking: All orders include tracking.
- Free Shipping: Available on select products or orders over $200 (if applicable).
- Expedited Shipping: Options available at checkout.
🔄 Return Policy
- Return Window: Items can be returned within 15 days of delivery.
- Conditions: Products must be unused and in original packaging.
- Non-Returnable: Assembled racks, clearance items, and custom orders are final sale.
- Process: Contact us at [your email] to request a return authorization.
- Shipping Costs: Return shipping is the buyer’s responsibility unless the item was defective or incorrect.
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Tech specs.
View all specifications
| System | |
| OS | Embedded Linux |
| Compression | H.265S / H.265+ / H.265 / H.264 |
| Recording | Dual-stream, 24/7 · manual / timed / motion / sensor / smart events |
| Video | |
| IP Input | 16 CH, up to 8 MP (3840 × 2160) |
| Incoming Bandwidth | 160 Mbps |
| Outputs | HDMI ×1 (up to 4K) · VGA ×1 (1080p) |
| Decoding | 1× 8MP @30fps or 6× 1080p @30fps |
| Playback | 16 CH simultaneous · smart search |
| AI & Smart Events | |
| Face Detection | 16 CH (AI by camera) · 2 CH (on-device AI) |
| Classification | Human & vehicle — 16 CH by camera / 2 CH on-device |
| Statistics | Bar graphs by day / week / month / quarter / custom |
| Smart Events | Cross line, intrusion, region entrance / exit |
| Extras | Fisheye dewarping · license plate recognition (AI cameras) |
| Audio | |
| Input | 16 CH IPC audio · RCA in (two-way audio) |
| Output | RCA ×1 · G.711 (U/A) |
| Network | |
| PoE Ports | 16 × 10/100M RJ45 · IEEE 802.3af |
| Uplink | RJ45 10/100/1000 Mbps ×1 |
| Protocols | TCP/IP, IPv6, DHCP, DDNS, UPnP, NTP, RTSP, SNMP, WebSocket, HTTP(S), ONVIF |
| Clients | Up to 64 users |
| Storage & Ports | |
| HDD | 2 × SATA 3.0, up to 10 TB each |
| Alarm | 4 CH input · 1 CH output · IPC alarm supported |
| USB / Serial | USB 2.0 × 2 · RS485 (PTZ / keyboard) |
| General | |
| Power | ≤15 W (without HDD / PoE load) |
| Dimensions | 380 × 268 × 45 mm (15.0" × 10.6" × 1.8") |
| Mobile Apps | Free iOS & Android apps · remote live view, playback & push alerts |
| Certification | CE, FCC · RoHS / REACH / WEEE compliant |
| Operating | -10°C to 50°C · 10–90% RH |
| Region | NTSC · USA plug |
| Warranty | 24 months |
Tools & documents.
🖥️ NVMS Desktop Software
Multi-site live view, playback and device management for Windows.
Software & tools →Your whole system.
In your pocket.
The recorder registers itself with a secure P2P cloud relay the moment it goes online. In the app you tap Add Device, scan the QR code shown on the recorder’s screen, and the app connects directly to your system over WiFi, 4G or 5G — no static IP, no DDNS, no port forwarding. Add unlimited recorders and share access with family or staff. The app is completely free, with no subscription.
Live MultiviewWatch up to 16 channels per screen with instant channel switching.
Timeline PlaybackScrub the recording timeline, then download clips straight to your phone.
One-Tap ArmingArm or disarm alarms remotely and get push alerts the moment something happens.
Snapshot LibrarySnapshots and exported clips organized by date, ready to share.Works with every Ironpixel camera.
Connect any of these IP cameras over PoE or the LAN — the recorder auto-detects them with zero configuration.
